Name: DA 2518
Brand: Miele
SKU: 10868930
Price: 133000 THB
Availability: InStoreOnly

Official Miele website

01 / 02

Colour:Stainless steel

฿133,000.00

All product prices incl. VAT at null%.

Product details

Customised kitchen design - fully integrated in 1102 mm width
Unique user convenience –
Con@ctivity
Powerful – 785 m3/h in Booster level
Efficient filtration-
10-ply stainless-steel grease filter
Safe and easy to clean -
Miele CleanCover
View manufacturer details:
Safety Information

Product data sheet

Model identifier: DA 2518
Manufacturer material number: 10868930
EAN number: 4002516011408
Marketing class: Gold

Integrated extractor

Type of air guide: Can be retrofitted
Recirculation conversion kit (order separately): DUU 151
Active charcoal filter (order separately): DKF 15-P

Colour: Stainless steel

Miele@home
Con@ctivity: Yes
Electronic controls
Controls: Light-touch switches with LEDs
Miele@mobile app
Power levels (number without Booster level): 3
Booster levels: 1
Run-on time 5/15 min.
Grease filter saturation indicator
Active charcoal filter saturation indicator
Easy-to-clean canopy interior – CleanCover

Google voice control
Push notifications
RemoteUpdate
Smart Home Integration

Number of dishwasher-safe stainless steel grease filters (10-ply): 3

Number x W: 4 x 3 W
Light intensity in Lx: 520 lx
Colour temperature in K: 3000 Kelvin

Fan power (m³/h): 890
Dual-action blower

Air throughput in Level 1 (m³/h) according to EN 61591: 290
Air throughput in Level 2 (m³/h) according to EN 61591: 425
Air throughput in Level 3 (m³/h) according to EN 61591: 575
Air throughput in Booster level 1 (m³/h) according to EN 61591: 785
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3: 48
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3: 55
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-3: 63
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-3: 70
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13: 35
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13: 42
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13: 50
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-13: 57

Air throughput in Level 1 (m³/h) according to EN 61591: 250
Air throughput in Level 2 (m³/h) according to EN 61591: 375
Air throughput in Level 3 (m³/h) according to EN 61591: 500
Air throughput in Booster level 1 (m³/h) according to EN 61591: 625
Sound power in Level 1 (dB(A) re 1 pW) according to EN 60704-3: 59
Sound power in Level 2 (dB(A) re 1 pW) according to EN 60704-3: 65
Sound power in Level 3 (dB(A) re 1 pW) according to EN 60704-3: 70
Sound power in Booster level 1 (dB(A) re 1 pW) acc. to EN 60704-3: 74
Sound pressure in Level 1 (dB(A) re 20 µPa) according to EN 60704-2-13: 46
Sound pressure in Level 2 (dB(A) re 20 µPa) according to EN 60704-2-13: 52
Sound pressure in Level 3 (dB(A) re 20 µPa) according to EN 60704-2-13: 57
Sound pressure in Booster level 1 (dB(A) re 20 µPa) acc. to EN 60704-2-13: 61

Safety shut-off

Canopy dimensions (W x H x D) in mm: 1102 x 50 x 402
Canopy width in in. (mm): 1102
Canopy height in in. (mm): 50
Depth of hood canopy in in. (mm): 402
Net weight in kg: 14.3
Length of supply lead in m: 1.5
Standard plug fitted
Total rated load in kW: 0.307
Voltage in V: 230
Fuse rating in A: 10
Frequency in Hz: 50
Number of phases: 1

Extraction ducting connection at top
Diameter of extraction ducting connection in mm: 150
Combination with WiFi-enabled Miele hob: recommended

Non-return flap

EAN: 4002516011408

What's included

Non-return flap

*This is a separate digital offer from Miele & Cie. KG. The range of functions can vary depending on the model and the country. Acceptance of the Terms and Conditions and Privacy Policy for Miele digital products and services in the Miele app required. Miele reserves the right to change or discontinue the digital offer at any time.

More convenience when cooking
Con@ctivity
The cooker hood reacts automatically to the hob and the oven.
Easy to use and effective against grease
Stainless steel grease filters (10-layer)
Looks great and does a good job: effective grease filtering and easy cleaning in a dishwasher.
Convenience and safety in detail
Miele CleanCover
Protection and easy cleaning: the sealed, smooth surface prevents contact with cables and the motor.

User convenience

More convenience when cooking

Con@ctivity

The cooker hood reacts automatically to the hob and the oven.

Automatic fan run-on

Run-on function

Odour-free room air: after cooking, the fan can be set to switch off automatically after a 5 or 15 minute run-on period.

Countdown time conveniently in view

Filter indicator

Easy filter replacement: a red light lets you know when the grease and/or active charcoal filter is saturated.

Safety

Always on the safe side

Safety switch-off

Sensible, even in case of operating errors: the cooker hood switches off automatically after 10 hours.

Features

Easy to use and effective against grease

Stainless steel grease filters (10-layer)

Looks great and does a good job: effective grease filtering and easy cleaning in a dishwasher.

Convenience and safety in detail

Miele CleanCover

Protection and easy cleaning: the sealed, smooth surface prevents contact with cables and the motor.

Smart Extras

Always up to date with software updates
RemoteUpdate^2,
Bringing new functions directly to your appliance.
Everything at a glance with smart notifications
Push notifications^2,
Receive relevant information directly on your smartphone or tablet.
Seamless networking throughout your home
Smart Home Integration^2,
Intelligent integration of Miele appliances into a Smart Home system.
A spark of magic for the kitchen
Voice control^2,^3,
Convenient operation via voice control.

Matching products and accessories

Condensation trap

Prevents condensation from re-entering the cooker hood canopy.

Odour filter with active charcoal

for Miele DA 25xx/2450/2580 cooker hoods.

Recirculation conversion kit for DA 3xxx/2xxx and DAS 2xxx, 4xxx and 8xxx

to convert slimline/integrated cooker hoods from extraction to recirculation.

Silencer

for reducing air and motor noises.

Silencer connection

between silencer and connector.

Reducing collar

for reducing the exhaust air vent cross-section.

Wall box

for extraction.

Active AirClean charcoal filter

for Miele DA 25xx/2450/2580 cooker hoods.

Electronic module

for additional functions on all DA with Con@ctivity 3.0/WiFi

Downloads

Operating instructions/Installation instructions

PDF

Download

dwg

ZIP

Download

fbx

ZIP

Download

ifc

ZIP

Download

rfa

ZIP

Download

rvt

ZIP

Download

Whether you are looking to replace an appliance or plan a new kitchen – you will find all the relevant installation drawings for your Miele appliance here. Please note that our products should only be installed and maintained by authorised experts. In the event of queries, please ring us for some no-obligation advice!

https://media.miele.com/dam/f98556da-d05c-4df7-b6e4-b3bd002e6410/20000128441_HighresDigitalRGB.png

Descriptions

DA 2518 (Installation drawing)

1) Vent connection alternatively to rear, You will find further detailed measurements in the instructions for use!

POSTSCRIPT

Download

1.All product prices incl. VAT at null%.
2.This is a separate digital offer from Miele & Cie. KG. The range of functions can vary depending on the model and the country. Acceptance of the Terms and Conditions and Privacy Policy for Miele digital products and services in the Miele app required. Miele reserves the right to change or discontinue the digital offer at any time.
3.Voice control uses the Google LLC and Amazon Alexa services and is based on their availability. The range of functions can vary depending on the country. Google, Google Home and Google Nest Mini are trademarks of Google LLC. Google Nest Mini requires WiFi, an internet connection, a nearby power socket, a Google account and a compatible mobile device. Minimum requirements for the operating system can be found at: g.co/home/req. Compatible with Alexa. Amazon, Alexa and all associated trademarks are trademarks of Amazon.com, Inc. or their affiliated companies.

We reserve the right to make technical changes; we assume no liability for the accuracy of the information provided.

DA 2518 Stainless steel
